Honeywell S05010-SW1 Modulating Direct Coupled Actuator

Name: HONEYWELL S05010-SW1 MODULATING DIRECT COUPLED ACTUATOR
SKU: 1079995
Availability: LimitedAvailability

honeywell-S05010-SW1-modulating-direct-coupled-actuator-(New)

honeywell-S05010-SW1-modulating-direct-coupled-actuator-(New)-1

honeywell-S05010-SW1-modulating-direct-coupled-actuator-(New)-2

honeywell-S05010-SW1-modulating-direct-coupled-actuator-(New)-3

Neu

Auf Lager2 EinheitenVersandbereit

Modulating Direct Coupled Actuator

The Honeywell S05010-SW1 actuator offers precise damper and valve control with 24 V AC/DC operation, IP54 protection, and 90° rotation for HVAC and automation systems.

Hersteller

HONEYWELL

SKU

1079995

Kategorie

Electric Rotary Actuator

Zustand

Neu

24v Ac/Dc Actuator Control coupled damper Direct Honeywell Hvac Industrial IP54 Modulating MS7505B2130 S05010 S05010-SW1 Series

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Honeywell S05010-SW1 Modulating Direct Coupled Actuator

The Honeywell S05010SW1 Modulating Direct Coupled Actuator is designed for precise control of HVAC dampers and valves. It provides accurate modulation, efficient operation, and long-term reliability in demanding industrial and building automation systems.

Manufacturer: Honeywell

Type: Modulating Direct Coupled Actuator

Model: S05010-SW1

Part No.: MS7505B2130 / 50032258-028

Series: S05010

Rated Nominal Voltage	24 V AC / DC
Power Consumption	6.3 W
Frequency	50 / 60 Hz
Auxiliary Contact Switch	SPDT 1 Changeover (CO)
Switching Capacity Auxiliary Switch	250 V AC, 8/5 A
Switching Points Auxiliary Switch	5° / 80°
Control Signal	(0) 2-10 V DC, Floating (3-Point)
Actuator Opening Time	90 s
Angle of Rotation Max.	90°
Protection Class	IP54
Ambient Temperature	-40 / 60 °C
Dimensions	177 Ã— 98 Ã— 80 mm
