IFM IZ5034 Inductive Sensor
Hochpräziser induktiver Sensor mit einem Erfassungsbereich von 0,8 mm, Gehäuse aus Edelstahl und IP65-Schutz. Entwickelt für industrielle Automatisierungsanwendungen.
IFM IZ5034 Inductive Sensor - IZB30,8-BPKG/V2A/AS-514-TPS RT
The IFM IZ5034 is a high-performance inductive sensor designed for accurate and reliable object detection in industrial applications. With a 0.8 mm sensing range and robust stainless steel housing, this sensor offers durability, precision, and efficient operation in challenging environments.
Key Product Details:
Manufacturer: IFM
Type: Inductive Sensor
Model: IZB30,8-BPKG/V2A/AS-514-TPS RT
Part No.: IZ5034
This inductive sensor is ideal for industrial automation applications, providing reliable and precise object detection while ensuring robust performance in harsh conditions.
| Sensing Range | 0.8 mm |
| Operating Distance | 0 to 0.65 mm |
| Operating Voltage | 10 to 36 V DC |
| Current Consumption | 15 mA |
| Switching Rating | 2.5 V DC, 100 mA |
| Switching Frequency | 800 Hz |
| Electrical Design | PNP |
| Output Function | Normally Open |
| Housing | Cylindrical |
| Mounting | Flush Mountable |
| Material | Stainless Steel |
| Protection Degree | IP65 |
| Type of Short-Circuit Protection | Pulsed |
| Ambient Temperature | -25 to 80°C |
| Diameter, Length | 4 mm, 49 mm |
