IFM KG5008 Capacitive Sensor

Manufacturer: IFM
Type: Capacitive sensor
Model: KG5008
MRN: KG-3008-ANKG

Electrical design: NPN
Output function: normally open
Sensing range[mm]: 2.5 … 8
Housing: threaded type
Materials: PBT
Dimensions[mm]: M18 x 1 / L = 85
Operating voltage[V]: 10…36 DC
Current consumption[mA]: 10; (24 V)
Protection class: II
Max. voltage drop switching output DC[V]: 2.5
Permanent current rating of switching output DC[mA]: 250
Switching frequency DC[Hz]: 50
Correction factor: glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2
Connection: Cable: 2 m, PVC; 3 x 0.5 mm²
Ambient temperature[°C]: -25…80
Protection: IP 67
