INA 81218-TV Axial Cylindrical Roller Bearing

Manufacturer: Schaeffler INA

Type:  Axial cylindrical roller bearings

Model: 81218TV

Replaces: 81218 TN

Dimensions:

Inner diameter shaft washer d: 90 mm

Outer diameter housing washer D: 135 mm

Height T: 35 mm

Dynamic load rating, axial: 290000 N

Static load rating, axial: 890000 N

Fatigue load limit, axial: 95000 N

Limiting speed: 2550 RPM

Reference speed: 910 RPM

Operating temperature: -30 … +120 °C

Cage material: Plastic Cage made from PA66
