INA Nkib 5914 Needle Roller / Angular Contact Ball Bearing
Nadelkugel- / Winkelkontaktkugellager INA NKIB 5914 Nadelkugel- / Winkelkontaktkugellager mit 70 mm Bohrungsdurchmesser und 100 mm Außendurchmesser. Es bietet hohe dynamische und statische Tragzahlen und ist geeignet für anspruchsvolle radiale und axiale Lastanwendungen mit einer Grenzdrehzahl von 5.800 1/min.
INA Needle Roller / Angular Contact Ball Bearing NKIB 5914
The INA Needle Roller / Angular Contact Ball Bearing NKIB 5914 is designed to handle both radial and axial loads with high performance and durability. It offers high load capacities and operates efficiently in demanding industrial applications.
Manufacturer: INA
Model: NKIB 5914
Type: Needle Roller / Angular Contact Ball Bearing
| Bore Diameter (d) | 70 mm |
| Outer Diameter (D) | 100 mm |
| Width (B) | 45 mm |
| Width of Outer Ring (C) | 40 mm |
| Dynamic Load Rating (Cr) | 95,000 N |
| Static Load Rating (C0r) | 156,000 N |
| Dynamic Axial Load Rating (C) | 16,800 N |
| Static Axial Load Rating (C0) | 44,500 N |
| Fatigue Load Rating | 28,000 N (radial), 2,020 N (axial) |
| Limiting Speed | 5,800 1/min |
| Reference Speed | 4,900 1/min |
