INA PWKR52-2RS-A Stud Type Track Roller
Bolzenartige Laufrolle Die Schaeffler INA PWKR52-2RS-A Bolzenartige Laufrolle verfügt über einen Außendurchmesser von 52 mm, eine dynamische Traglast von 25500 N und eine 2RS-Abdichtung und bietet eine stabile und leistungsstarke Linearbewegung für industrielle Systeme.
Schaeffler INA PWKR52-2RS-A Stud Type Track Roller
The Schaeffler INA PWKR52-2RS-A Stud Type Track Roller is designed for heavy-duty applications requiring high radial load capacity, stability, and precision. Featuring protected lip seals on both sides and a robust stud type construction, this track roller ensures reliable operation in demanding environments.
Manufacturer: Schaeffler INA
Type: STUD TYPE TRACK ROLLER
Model: PWKR52-2RS-A
Basic Load Ratings (Radial):
This Schaeffler INA stud type track roller provides reliable performance under high radial loads, ensuring smooth and stable motion for a wide range of industrial applications.
| Outside Diameter (D) | 52 mm |
| Fit Diameter of Roller Stud (d1) | 20 mm |
| Width of the Roller Stud (B) | 66 mm |
| Width of Thrust Washer (B1) | 25.6 mm |
| Thread (G) | M20X1.5 |
| Thread Length | 21 mm |
| Dynamic Load Rating (Cr w) | 25500 N |
| Static Load Rating (C0r w) | 33500 N |
| Fatigue Load Limit (Cur w) | 4200 N |
| Permissible Static Load, Radial | 33500 N |
| Permissible Dynamic Load Outer Ring, Radial | 21800 N |
| Speed on Permanent Grease Lubrication | 3800 1/min |
| Sealing | 2RS, Protected lip seal on both sides |
