INA ZM 35 Precision Locknut

Manufacturer: INA
Type: PRECISION LOCKNUT ZM
Model: ZM 35

Dimensions:
Thread d: M35X1,5
Plant diameter outside d₁: 47 mm
Outside diameter D: 52 mm
Height h: 12 mm
Mounting torque set screw: 5 Nm
Breaking load, axial F_aB: 134000 N
Breakaway M_L: 80 Nm
Mounting torque reference M_AL: 40 Nm
