Kaller M2/38.1 GAS Spring Actuator

Kaller M2/38.1 Gas Spring Actuator

The Kaller M2/38.1 Gas Spring Actuator is designed for high-performance applications requiring precise force and motion control. With a compact design and optimized force generation, this gas spring actuator offers exceptional durability and reliability in industrial systems.

Manufacturer: KALLER

Type: Gas Spring Actuator

Model: M2/38.1

Technical Data:

• Piston Diameter: 25 mm
• Stroke: 38 mm
• Total Length: 118 mm
• Rod Diameter: 12 mm
• Charging Pressure (Psi): 1958
• End Force At Full Stroke (LBF): 695
• Force Increase By Temperature Percent Per (°F): 0.17
• Gas Volume (CuF): 0.00052972
• Initial Force at Max. Pressure (LBF): 340
• Max Charging Pressure (Psi): 2610
• Max Piston Rod Velocity (FtMin): 314.96
• Max. Operating Temperature (°F): 176
• Min Charging Pressure (Psi): 362
• Min. Operating Temperature (°F): 32
