Kinco MT4414TE Human Machine Interface HMI
Neu
Auf Lager1 EinheitVersandbereit
399,99$
Human-Machine Interface (HMI)
The Kinco MT4414TE HMI features a 7-inch TFT display, 24 V DC operation, multiple communication ports, and IP65 protection, ensuring smooth control and monitoring in automation systems.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Kinco MT4414TE Human Machine Interface (HMI)
The Kinco MT4414TE Human-Machine Interface (HMI) from the MT4000 series is a high-performance operator panel designed to provide intuitive control and real-time monitoring for industrial automation systems. With a vivid 7-inch TFT display and advanced communication options, it ensures precise visualization and reliable connectivity in demanding environments.
Manufacturer: Kinco
Type: Human-Machine Interface HMI
Model: MT4414TE
Ref. No.: 060640161449006
| Series | MT4000 |
| Display Design | 16:9 TFT |
| Screen Diagonal | 7 In |
| Resolution | 800 x 480 Pixels |
| Colors No. | 65,536 Colors |
| Backlight | LED |
| Brightness | 300 cd/m² |
| Supply Voltage | 24 V DC |
| Rated Power | 4 W |
| Touch Panel | 4-Wire Precision Resistance Network |
| Memory | 128M FLASH, 64M SDRAM |
| Expandable Memory | 1 USB Host |
| Recipe Memory & RTC | 512 KB & RTC |
| Ethernet | 10/100 Base-T |
| Processor | 32-bit RISC CPU 800 MHz |
| Program Download | USB Slave / Serial Port / Ethernet Port |
| COM Port | COM0: RS232/RS485-2/RS485-4, COM2: RS232 |
| Protection Class | IP65 |
| Ambient Temperature | 0 / 50 °C |
| Dimensions | 204 x 150 x 37 mm |
