Kobold DCM 10 Pressure Switch

Kobold DCM10 Pressure Switch

A robust and dependable pressure switch designed by Kobold for industrial environments requiring accurate pressure monitoring and reliable switching performance. With its seawater-resistant aluminum housing and flexible mounting orientation, the DCM10 is built for durability and long-term operational stability. Manufacturer: Kobold
Type: Pressure Switch
Model: DCM10
Pressure: max. 10 bar
Switching device: rugged housing of seawater resistant aluminum die-casting GD Al Si 12
Fitting position: vertically upwards and horizontal. DCM 4016 and 4025 vertically upwards
Contact agreement: single-pole change-over switch
Switching capacity:
Voltage: 250 V AC
Current: 10 (5) A
Protection degree: IP 54
Max. ambient temperature at the switch unit: -25 to 70°C
Connection: G1/2

Recommendation:
The Kobold DCM10 Pressure Switch is an excellent solution for systems that require accurate pressure control, reliable switching performance, and durable construction capable of withstanding harsh industrial environments. Its robust seawater-resistant housing and IP54 protection make it ideal for hydraulic units, water treatment facilities, industrial pumps, and automation processes. For improved monitoring capability or system integration, we recommend exploring our full range of Pressure Switches and Sensors available through Platinum International to enhance safety, efficiency, and overall equipment performance.
