Leantechnik AG Lifgo 5.1 Linear Rack AND Pinion Gearbox

Name: LEANTECHNIK AG LIFGO 5.1 LINEAR RACK AND PINION GEARBOX
SKU: 982974
Price: 230.00 USD
Availability: LimitedAvailability

leantechnik-ag-lifgo-5-1-linear-rack-and-pinion-gearbox-2

leantechnik-ag-lifgo-5-1-linear-rack-and-pinion-gearbox-1

leantechnik-ag-lifgo-5-1-linear-rack-and-pinion-gearbox-3

leantechnik-ag-lifgo-5-1-linear-rack-and-pinion-gearbox-4

leantechnik-ag-lifgo-5-1-linear-rack-and-pinion-gearbox-5

Neu

Auf Anfrage verfügbar

230,00$

SKU

982974

Kategorie

Linear Motion

Zustand

Neu

AG AND Blocks Boxes Gear Gearbox Leantechnik Linear Motion Pinion Rack Roller Runner

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Manufacturer: Leantechnik Ag

Type: Rack and Pinion Gearbox

Model: LIFGO5.1LINEAR

Pinion Shaft Type: ZA 1

Lifting Power: 3800 N

Lifting Speed: 3 m/s

Acceleration: 50 m/s²

Torque: 76 Nm

Pitch Diameter: 40 mm

Lifting Gear Ratio: 125.6637 mm/360°

Efficiency: 0.92

Temperature Resistance: -10…80 °C

Static Torque: 760 Nm

Dynamic Torque: 330…390 Nm

Static Load Rating: 51200 N

Dynamic Load Rating: 25900 N

Shaft Diameter: 25 mm

Weight: 3.4 kg
