LM324N / 99140 Integrated Chip
Typ: Integrierter Chip Modell: LM324N Artikelnummer: 99140
Type: Integrated Chip
Model: LM324N
Part No.: 99140
Features:
•Internally frequency-compensated for unity gain
•Large DC voltage gain: 100dB
•Wide bandwidth (unity gain): 1MHz (temperature-compensated)
•Wide power supply range Single supply: 3 V DC to 30 V DC or dual supplies: ±1.5 V DC to ±15 V DC
•Very low supply current drain: essentially independent of supply voltage (1mW/op amp at +5VDC)
•Low input biasing current: 45nADC (temperature-compensated)
•Low input offset voltage: 2mVDC and offset current: 5nADC
•Differential input voltage range equal to the power supply voltage
•Large output voltage: 0 V DC to V CC -1.5 V DC swin
Supply Voltage: 3 … 30 V DC
No. of pins: 14
Operating Temperature: 0 … 70°C
