Moeller DILM15-10 Contactor

Manufacture: Moeller
Type: Contactor
Model: DILM1510
Art. No.: 290058

Used: for Motors
Coil voltage: 230 V AC@50 Hz,240 V AC@60Hz
Rated Operational Current le: 15.5 A
Rated impulse withstand voltage (Uimp): 8000 V AC
Power kw rating AC-3:
@380/400 V: 7.5 kW
Power kw rating AC-4:
@380/400 V: 3 kW
Contact: 1 Normally open contact
Degree of protection: IP20
Frame size: FS1
No. of poles: 4
Pollution degree: 3
Terminals: Screw terminals
Ambient operating temperature: -25 … 60°C
Dimensions: 75 x 68 x 45 mm
