Moeller T0-1-15431/E Changeover Switch
Neu
Auf Lager1 EinheitVersandbereit
Moeller / Eaton Umschalter / Steuerschalter T0115431/E mit einer Nennspannung von 960 V AC, 12 A Strom, Schutzart IP65 und Kippschalter. Geeignet für den industriellen Einsatz mit Flächenmontage und Hand-Aus-Auto Beschriftung.
0660126947960aActuatorChangeoverControlCurrentEatonFlushHand-Off-AutoIECImpulseIP65kVMoellerMountingRatedSwitchToggleVVDEvoltage
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Moeller / Eaton Changeover Switch / Control Switch T0115431/E
Moeller / Eaton Changeover Switch / Control Switch T0115431/E is a high-quality, reliable switch designed for industrial applications. This control switch is engineered for maximum performance and durability, making it ideal for switching applications in environments requiring robust and reliable control mechanisms.
- Manufacturer: Moeller / Eaton
- Type: Changeover Switch / Control Switch
- Model: T0115431/E
- Order No.: 019872 052
- Series: T0
Technical Data:
- Rated Voltage (Ue): 960 V AC
- Rated Current (Ie): 12 A
- Rated Operational Current at AC-15 at 415 V: 4 A
- Rated Breaking Capacity at 400/415 V: 110 A
- Rated Operational Power at AC-23A at 380 to 440 V: 6.5 kW
- Rated Operational Power at AC-3 at 380 to 440 V: 4/2.2 kW
- Rated Impulse Voltage (Uimp): 6 kV
- Switching Angle: 45 degrees
- Number of Contacts: 2
- Number of Poles: Single-pole
- Pollution Degree: 3
- Actuator Type: Toggle
- Fitted with: 0 (off) position black thumb grip and front plate
- Inscription: HAND-0-AUTO
- Mounting: Flush mounting
- Protection Class: IP65
- Standard: IEC 947, EN 60947, VDE 0660
- Ambient Operating Temperature: -25 to 50 °C
- Dimensions: 76 x 48 x 48 mm
