Norgren RM/547/70 ISO Cylinder
Neu
Auf Lager1 EinheitVersandbereit
ISO Cylinder
NORGREN ISO Cylinder RM/547/70 features a 63 mm bore diameter and 70 mm stroke. With a pressure range of 2 to 10 bar and G 3/8 pneumatic connection, it offers reliable performance in compressed air systems.3/863AirboreCompressedconnectionCylinderDoubleEndGIndustrialISOmalemmNorgrenOperationPistonPneumaticRM/547/70RODSquare
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
NORGREN ISO Cylinder RM/547/70
The NORGREN ISO Cylinder RM/547/70 is a high-quality pneumatic cylinder designed for reliable operation in industrial applications. With a bore diameter of 63 mm and a stroke of 70 mm, this cylinder provides efficient performance for a variety of compressed air systems.
Manufacturer: NORGREN
Model: RM/547/70
Technical Specifications
- Media: Compressed Air
- Bore Diameter: 63 mm
- Stroke: 70 mm
- Bore x Stroke: 63 x 70 mm
- Rod Diameter: 16 mm
- Frame Dimensions: 75 x 180 mm
- Pneumatic Connection: G 3/8
- Pressure: 2 / 10 bar
- Operation Mode: Double
- Piston Rod End: Male
- Shape: Square
- Rod Direction: One Side
