Pauly JP193 E2 HD STH4 Reflex Light Barrier

Name: PAULY JP193 E2 HD STH4 REFLEX LIGHT BARRIER
SKU: 1062779
Availability: LimitedAvailability

pauly-JP193-E2-HD-STH4-reflex-light-barrier-(Used)

pauly-JP193-E2-HD-STH4-reflex-light-barrier-(Used)-1

pauly-JP193-E2-HD-STH4-reflex-light-barrier-(Used)-2

Gebraucht

Auf Lager1 EinheitVersandbereit

Reflex Light Barrier

The PAULY JP193 E2 HD STH4 Reflex Light Barrier offers a reliable sensing solution with a maximum range of 15 m, 650 nm wavelength, and robust relay output ratings. Designed for industrial use, it features a plug connector and operates within a wide temperature range.

Hersteller

PAULY

SKU

1062779

Kategorie

Sensors

Zustand

Gebraucht

15 24 25 60 650 Al Ambient Barrier C Cast Connector dc Detection E2 HD Industrial JP193 Light M Nm NPN Pauly Plug PNP Range Reflex Relay Sensing STH4 supply Temperature Transistor Type V voltage

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

PAULY JP193 E2 HD STH4 Reflex Light Barrier

The PAULY JP193E2HDSTH4 Reflex Light Barrier is a high-performance sensing solution designed for reliable distance measurement and object detection. With a maximum sensing range of 15 m and a wavelength of 650 nm, this device provides precise and efficient operation in a variety of industrial environments.

Manufacturer: PAULY

Type: Reflex Light Barrier

Model: JP193 E2 HD STH4

Sensing Range Max.	15 m
Wave Length	650 nm
Supply Voltage	24 V DC
No-Load Current Max.	40 mA
Switching Output	Relay, PNP / NPN-Transistor
Relay Output Ratings	240 V AC, 50 A, 120 W / 1200 VA
Connector Type	Plug
Material	Al Cast
Ambient Temperature	-25 / 60 °C
Dimensions	100 x 30 x 65 mm
