Pepperl Fuchs NBN4-12GM60-A2-V1 Inductive Sensor

Manufacturer: Pepperl+Fuchs

Type: Inductive Sensor

Model: NBN4-12GM60-A2-V1

Part No: 84010

Rated Operating Distance: 4 mm

Assured Operating Distance: 0 … 3.24 mm

Operating Voltage: 10 … 30 V DC

Switching Current: ≤ 200 mA

No-Load Supply Current I₀: ≤ 15 mA

Voltage Drop U_d: ≤ 2 V

Signal Output: PNP

Switching Function: Complementary

Switching Frequency f: 0 … 1200 Hz

Installation: Non-Flush

Protection Degree: IP67

Ambient Temperature: -25 … 70 °C

Material: Housing: Brass, Nickel-Plated, Sensing Face: PBT

Connection: Connector M12 x 1 , 4-pin

Diameter, Length: 12, 70 mm

Weight: 0.02 kg
