Pepperl+Fuchs NBN4-12GM40-E2 Inductive Sensor

Manufacturer: PEPPERL FUCHS

Type: INDUCTIVE SENSOR

Model No.: NBN412GM40E285

Part No.: 83311

Rated operating distance: 4 mm

Assured operating distance: 0 …. 3.24 mm

Operating Voltage: 10 … 30 V DC

Operating Current: 0 … 100 mA

Switching frequency: 0 … 800 Hz

Electrical design: PNP

Switching output: Normally open

Connector type: PVC Cable, 2 m

Protection class: II

Enclosure rating: IP67

Ambient Operating temperature: -25 … 70°C

Diameter, housing length: 12, 40 mm

Housing material: Brass, Nickel plated

Sensing face material: PBT

Mounting: Non-flush mountable

Condition: New
