Perry 1IO 0022/D15 Time Switch
Neu
Auf Lager1 EinheitVersandbereit
Digital Time Switch
The Perry 1IO0022/D15 is a 2-DIN digital daily and weekly time switch with up to 672 programmable events, 1 LCD display, and automatic daylight saving adjustment”ideal for precision lighting and load control.1IO0022/D15AutomationControlDailyDigitalDINIndustrialLightingPerryprogrammablerailSwitchTappetTimeTimerWeekly
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Perry 1IO0022/D15 Digital Daily Time Switch
The Perry 1IO0022/D15 is a versatile digital daily and weekly time switch designed for precise control of lighting, electrical loads, and automation functions. Featuring a circular 1 LCD display, tappet-based programmation, and DIN-rail installation, it delivers high reliability for civil, tertiary, and industrial applications. With up to 672 weekly programs, automatic daylight saving adjustment, and a rechargeable NiMH reserve battery, this timer ensures long-lasting and accurate performance.
Manufacturer: Perry
Type: Digital Daily Time Switch with Tappets and Display “ 2 DIN
Model: 1IO0022/D15
| Power Supply | 230 V AC, 50“60 Hz |
| Contact Output | 16 (2) A / 250 V AC |
| Maximum Programs | 96 (daily) / 672 (weekly) |
| Minimum ON/OFF Time | 15 minutes |
| Display | 1 Circular LCD |
| Maximum Lighting Load | 3500 VA (each contact) |
| Incandescent Lamps | 2300 W |
| Fluorescent Tube (Not Compensated) | 1000 W |
| Parallel Compensated Fluorescent Tubes | 290 W (total capacity 35 μF) |
| Compact Fluorescent Lamps | 105 W (7 × 15 W) |
| LED Load | Max 15 × 4 W / 10 × 8 W / 7 × 15 W |
| Terminal Wire Cross-Section | Up to 2.5 mm² |
| Protection Degree | IP20; IP30 (with covers); IP40 (rear of switchboard) |
| Output Type | Terminals with captive screw |
| Insulation Class | Class II |
| Relay Signal | ON/OFF shown on LCD |
| Reserve Type | NiMH rechargeable battery |
| Time Tolerance | ±1 sec/day |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | ˆ’10°C to +65°C |
| Installation Type | DIN rail / wall-mounted / rear of switchboard |
| Reserve Duration (R) | 360 hours |
| Housing | Thermoplastic, Grey RAL 7035 |
| Type of Use | Civil / Tertiary / Industrial |
| Controls | Programming keys, ON/OFF key |
| Clock Setting Accuracy | Digital (hours/minutes) |
| Daylight Saving Adjustment | Automatic |
| Dimensions (L × W × H) | 35 × 60 × 128 mm |
