Pfannenberg PF 32.000 Axial FAN

Name: PFANNENBERG PF 32.000 AXIAL FAN
SKU: 971117
Availability: LimitedAvailability

Neu

Auf Lager1 EinheitVersandbereit

Hersteller: Pfannenberg Typ: Axialventilator Modell: PF32000 Patr. Nr.: 11632101000

Hersteller

PFANNENBERG

SKU

971117

Kategorie

Axial Fans & Fan Filter Units

Zustand

Neu

Axial Ebmpapst Fans Industrial

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Manufacturer: Pfannenberg
Type: Axial Fan
Model: PF32000
Patr. No: 11632101000

Frame Shape: Square Frame
No. of Blades: 5
Dimensions (mm): 223x223x90
Cut Out Dimensions (mm): 177×177
Direction: Push
Voltages (V AC): 230
Temperature (°C): -40 … 50
Power Rating (W): 18-19
Flow Rate (m3/h): 98-108
Flow Rate (CFM): 57.98-63.90
Current (mA): 120-180
Frequency (Hz): 50/60
Inverter: without Inverter
Number of Wires: 2
Blade material: Metal

Spezifikation	Wert
Weight	1,02 kg
Condition	New
Part No.	11632101000
No. of Wires	2
Manufacturer	PFANNENBERG
Type of Product	Axial Fan
Frame Shape	Square Frame
No. of Blades	5
Inverter	Without Inverter
Direction	Push
Voltage Type	AC
Frequency [Hz]	50/60
Blade Material	Metal
Voltage [V]	230
Power [kW]	0.018-0.019
Shelf No.	240528
Dimensions [mm]	223x223x90
Installation Cutout [mm]	177x177
Current [A]	0.12-0.18
Temperature [°C]	-40 / 50
Flow Rate [m3/h]	98-108
Flow Rate CFM	57.98-63.90
