Phoenix Contact DK-BIC-35 Feed-Through Terminal Block

Name: PHOENIX CONTACT DK-BIC-35 FEED-THROUGH TERMINAL BLOCK
SKU: 1017510
Availability: LimitedAvailability

phoenix-contact-DK-BIC-35-feed-through-terminal-block-(used)

phoenix-contact-DK-BIC-35-feed-through-terminal-block-(used)-1

phoenix-contact-DK-BIC-35-feed-through-terminal-block-(used)-2

Gebraucht

Auf Lager2 EinheitenVersandbereit

Typ: Durchgangsklemme

Hersteller

PHOENIX CONTACT

SKU

1017510

Kategorie

Safety Relays

Zustand

Gebraucht

Block Contact Phoenix Relay Safety terminal

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Manufacturer: PHOENIX CONTACT
Type: Feed-through terminal block
Model: DK-BIC-35
Part No.: 2749880

Rated voltage: 500 V AC/DC
Impulse discharge current (10/350) µs, charge: 50 As
Impulse discharge current (10/350) µs, specific energy: 2.5 MJ/Ω
Impulse discharge current (10/350) µs, peak value limp: 100 kA
Maximum continuous voltage UC: 500 V AC
500 V DC
Degree of protection: IP20
Ambient temperature (operation): -40 °C … 85 °C
Dimensions:
Width: 17.7 mm
Height: 89.8 mm
Depth: 65.5 mm
