Phoenix Contact SACC-MR-4CON-PG7-M SCO Connector

Manufacture: Phoenix Contact
Type: Connection Cable
Model: SACCMR4CONPG7MSCO
Order No.: 1542981

Nominal voltage UN: 250 V AC, 250 V DC
Nominal current IN: 4 A
Rated surge voltage: 2.5 kV
Outside diameter: 4 … 6 mm
Diameter housing: 20 mm
Number of positions: 4
No. of cable outlets: 1
Contact material: CuZn
Pollution Degree: 3
Connection method: Screw connection
Length: 41 mm
Standard designation: M12 connector
Degree of protection: IP67
Ambient temperature (operation): -40 … 85 °C
