Schneider 04045 Distribution Block
Neu
Auf Lager1 EinheitVersandbereit
Distribution Block
The Schneider LINERGY DX 125 (04045) is a 4-pole distribution block rated for 690V AC and 125A, with a robust design for safe and efficient power distribution.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Schneider LINERGY DX 125 Distribution Block
The Schneider LINERGY DX 125 (Part No. 04045) is a compact and high-performance distribution block designed for reliable power distribution in industrial and commercial applications. Built to withstand high voltages and ambient temperatures, it ensures secure and efficient electrical connectivity.
Manufacturer: Schneider
Type: Distribution Block
Model: LINERGY DX 125
Part No.: 04045
| Range | Linergy |
| Poles Description | 4P |
| Rated Operational Voltage (Ue) | 690 V AC |
| Rated Insulation Voltage (Ui) | 750 V AC |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Operational Current (Ie) | 125 A at 40 °C |
| Ambient Temperature Operation | -25 / 55 °C |
| Dimensions (H x W x D) | 127 x 108 x 48 mm |
