Schneider LC1F800 Contactor Body Without Coil
Neu
Auf Lager1 EinheitVersandbereit
Contactor Body Without Coil SCHNEIDER LC1F800 industrial contactor body from the TeSys F range designed for motor control and resistive load applications with high operational current and reliable switching performance.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Part No. | 074707 |
| S/N | 02211200353 |
| T/D | PK214931613 |
| Code | 3389110747072 |
| Range | TeSys |
| Range of Product | TeSys F |
| Product or Component Type | Contactor |
| Device short name | LC1F |
| Contactor application | Motor control,Resistive load |
| Poles description | 3P |
| [Ue] rated operational voltage | 1000 V AC 50/60 Hz , 460 V DC |
| [Ie] rated operational current | 1000 A 104 °F (40 °C)) <= 440 V AC AC-1 |
| [Uimp] rated impulse withstand voltage | 8 kV |
| Overvoltage category | III |
| Rated Power at 400 VAC | 450 Kw |
| [Ith] conventional free air thermal current | 1000 A (at 104 °F (40 °C)) |
| Rated breaking capacity | 6400 A conforming to IEC 60947-4-1 |
| Product Certifications | CB, CSA, LROS ,ABS,CCC,UL,UKCA |
| Compatibility code | LC1F |
| Height | 12.0 in (304 mm) |
| Width | 12.2 in (309 mm) |
| Depth | 12.2 in (309 mm) |
| Standard | IEC / EN 60947-4-1 |
| Ambient air temperature for operation | 23…131 °F (-5…55 °C) |
| Stock Key | CON-003 |
| Condition | New |
| SKU | 1099317 |
| Weight | 17,58 |
