Sick WTB2S-2P3275S36 Miniature Photoelectric Sensor
Neu
Auf Lager1 EinheitVersandbereit
Miniature Photoelectric Sensor SICK miniature photoelectric sensor with background suppression, PinPoint LED technology, PNP switching output, and IP67 protection for precise industrial detection applications.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Part No. | 1086470 |
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 7.7 mm x 21.8 mm x 13.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 4 mm ... 90 mm |
| Sensing range | 10 mm ... 70 mm |
| Type of light | Visible red light |
| Light source | PinPoint LED |
| Light spot size (distance) | 2.2 mm x 9 mm (45 mm) |
| Wave length | 640 nm |
| Adjustment | Cable |
| Supply voltage UB | 10 V DC ... 30 V DC |
| Ripple | 5 Vpp |
| Current consumption | 20 mA |
| Switching output | PNP |
| Switching mode | Light switchin |
| Switching frequency | 1000 Hz |
| Connection type | Cable with M8 male connector, 4-pin, 200 mm |
| Housing material | Plastic, ABS/PC |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Ambient operating temperature | -25 °C ... +50 °C |
| Stock Key | CON-003 |
| Condition | New |
| SKU | 1099221 |
| Weight | 0,03 |
