Siemens 3RW3013-1BB04 Soft Starter
Neu
Auf Lager2 EinheitenVersandbereit
SOFT STARTER
Siemens Sirius 3RW3013-1BB04 soft starter with 24 V AC/DC coil, 200“480 V operating voltage, 3.6 A current, and IP20 protection for reliable motor control.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SIEMENS SIRIUS 3RW30131BB04 SOFT STARTER
The Siemens Sirius 3RW3013-1BB04 soft starter is engineered to provide smooth motor starting and stopping, reducing mechanical stress and extending the lifetime of equipment. With compact dimensions and reliable performance, it is well-suited for industrial automation systems.
Manufacturer: Siemens
Brand Name: SIRIUS
Type: Soft Starter
Model: 3RW3013-1BB04
| Coil Voltage | 24 V AC/DC |
| Coil Voltage Frequency | 50 / 60 Hz |
| Rated Operating Voltage | 200 / 480 V AC |
| Operational Current | 3.6 A |
| Frequency | 50 / 60 Hz |
| Power AC-3 | 0.75 / 1.5 kW |
| Power Loss | 0.25 W |
| Insulation Voltage Ui | 600 V AC |
| Auxiliary Contact | 1 Normally Open (NO) |
| Protection Class | IP20 |
| Operation Temperature | -20 / 60 °C |
| Dimensions | 95 x 45 x 150 mm |
