Siemens 3VA1180-3GE46-0AA0 Circuit Breaker
Neu
Auf Lager2 EinheitenVersandbereit
The Siemens 3VA1180-3GE46-0AA0 SENTRON is a 4-pole molded case circuit breaker featuring an 80 A operational current, TM220 thermal-magnetic trip unit, 600 V AC/DC operating voltage, and up to 25 kA breaking capacity. Designed for reliable overload and short-circuit protection in industrial power distribution systems.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Brand Name | SENTRON |
| Design Of the Overcurrent Release | TM220 |
| FRAME | 160 N |
| Insulation Voltage | 800V |
| Operating Voltage | 600V AC/DC |
| Power Loss | Max.19,2W |
| Operational Current | 80A |
| Number Of Poles | 4 |
| Frequency | 50/60 Hz |
| short-circuit current breaking capacity (Icu) | (at 415V:25kA, 440V:16kA) |
| Switching Capacity Class of the Circuit Breaker | N |
| Arrangement Of Electrical Connectors | Front Terminal |
| Type Of Electrical Connection | box terminal on both sides |
| Ambient Temperature | -25 to 70 °C |
| Protection Degree | IP40 |
| Height | 130 mm |
| Width | 101,5 mm |
| Depth | 70 mm |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093371 |
| Weight | 1,3 |
