Siemens 6AG1134-4GD00-2AB0 Electronics Module

SIEMENS Electronics Module SIPLUS ET200S

The SIEMENS Electronics Module SIPLUS ET200S (Model: 6AG1134-4GD00-2AB0) is designed for reliable industrial applications with a wide operating temperature range from -25°C to 70°C. It features 8 digital inputs and operates at a rated DC value of 24 V. This module ensures high efficiency with a low power loss of 1.2 W. The input current from the backplane bus is a minimal 10 mA (at 3.3 V DC), making it an energy-efficient solution for industrial control systems.

🔧 Technical Specifications:

• Manufacturer: SIEMENS
• Type: Electronics Module
• Family: SIPLUS ET200S
• Model Number: 6AG1134-4GD00-2AB0
• Rated Value (DC): 24 V
• Input Current (from backplane bus 3.3 V DC, max): 10 mA
• Power Loss: 1.2 W
• Number of Digital Inputs: 8
• Ambient Temperature Range: -25 / 70 °C
• Dimensions (W x H x D): 15 mm x 81 mm x 52 mm
