Siemens 6ES7 148-4CA00-0AA0 Power Module
Zuverlässiges Siemens ET 200 PRO Leistungsmodul für 24 V DC elektronische Systeme. Bietet 10 A Kapazität, IP65/IP67 Schutz und kompakte Maße von 45 x 130 x 35 mm für flexible Einsätze.
SIEMENS 6ES7148-4CA00-0AA0 POWER MODULE
The Siemens 6ES7148-4CA00-0AA0 is a robust power module from the ET 200 PRO series, designed to deliver stable 24 V DC supply to electronic modules in harsh industrial environments. Engineered for high-performance field connectivity, it features reliable current handling and excellent ingress protection, making it ideal for distributed automation systems.
Manufacturer: Siemens
Type: Power Module
Model: 6ES7148-4CA00-0AA0
Family: ET 200 PRO
Use: For Electronic Modules ET 200 PRO PM-E, 24 V DC, incl. Bus Module, Connection Module PM-E 6ES7194-4BD00-0AA0 (Order Separately)
| Supply Voltage | 24 V DC |
| Input Current | 3 mA |
| Current Carrying Capacity | 10 A |
| Power Loss | 0.1 W |
| Isolation Tested With | 707 V DC |
| IP Degree of Protection | IP65, IP67 |
| Dimensions | 45 x 130 x 35 mm |
