Siemens 6ES7 307-1EA80-0AA0 Outdoor Power Supply
Outdoor Power Supply
The Siemens SIMATIC PS 307 Outdoor Power Supply provides 120/230 V AC input, 24 V DC output, 5 A rated current, and 120 W power, operating at up to 60 °C in industrial and outdoor applications.Siemens SIMATIC PS 307 Outdoor Power Supply
The **Siemens SIMATIC PS 307 Outdoor Power Supply** (Model: **S YSU/MD104467**) offers a versatile solution for powering industrial equipment in outdoor environments. It supports **120/230 V AC input voltage** with **2.1 / 1.2 A rated current** and operates within **50/60 Hz frequency**. The unit provides a stable **24 V DC output voltage**, delivering a **rated current of 5 A** and **120 W** of power. With a maximum operating temperature of **60 °C**, this power supply is designed for outdoor conditions. It uses **screw-type terminals** for easy connection and has an **IP20 protection degree**, ensuring it is safe for installation in a range of applications.
Manufacturer: Siemens
Type: Outdoor Power Supply
Model: S YSU/MD104467
MNR: 6ES7307-1EA80-0AA0
Family: SIMATIC PS 307
The **Siemens SIMATIC PS 307 Outdoor Power Supply** is designed to provide reliable and efficient power in outdoor and industrial environments, making it an ideal choice for powering a wide range of devices in harsh conditions.
| Input Voltage | 120/230 V AC |
| Rated Current (Input) | 2.1 / 1.2 A |
| Frequency | 50/60 Hz |
| Output Voltage | 24 V DC |
| Rated Current (Output) | 5 A |
| Power | 120 W |
| Temperature Range | Max. 60 °C |
| Connection Technology | Screw-type terminals |
| Degree of Protection | IP20 |
| Dimensions | 80 x 125 x 120 mm |
