Siemens 6ES7155-6AU01-0CN0 Interface Module
Neu
Auf Anfrage verfügbar
150,00$
Interface Module
A SIMATIC ET 200SP interface module designed for PROFINET-based distributed I/O systems, offering high data throughput, system redundancy support, and reliable operation in demanding industrial automation applications.155-6200SPaccessoriesAutomationDistributedETEthernetHFIMIndustrialInterfaceIOModulePLCPN/2ProfinetSiemensSimatic
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SIEMENS SIMATIC ET 200SP Interface Module IM 155-6 PN/2 HF
A high-performance interface module designed for decentralized automation systems, enabling fast and reliable PROFINET communication within SIMATIC ET 200SP distributed I/O stations. This module ensures stable data exchange, system redundancy support, and efficient power management for industrial automation environments. Manufacturer: SIEMENS
Type: Interface Module
Family: SIMATIC ET 200SP
MRN: 6ES7 155-6AU01-0CN0
Product Type Designation: IM 155-6 PN/2 HF
| Hardware Functional Status | From FS02 |
| Firmware Version | V4.2 |
| Supply Voltage (DC) | 24 V |
| Permissible Range, Lower Limit | 19.2 V DC |
| Permissible Range, Upper Limit | 28.8 V DC |
| Mains Buffering (Stored Energy Time) | 10 ms |
| Input Current (Max.) | 700 mA |
| Inrush Current (Max.) | 4.5 A |
| Power Loss (Typical) | 2.4 W |
| Address Space Per Module (Max.) | 288 Byte (Input And Output Data Respectively) |
| Address Space Per Station (Max.) | 1440 Byte |
| Maximum ET 200SP Modules | 64 |
| Maximum ET 200AL Modules | 16 |
| Number Of PROFINET Interfaces | 1 (2 Ports, Switch) |
| Interface Type | RJ45 (Ethernet) |
| Transmission Procedure | PROFINET, 100 Mbit/s Full Duplex (100BASE-TX) |
| Number Of Connections (Max.) | 16 |
| Redundancy Mode | PROFINET System Redundancy (S2), NAP S2 |
| Ambient Temperature (Horizontal Installation) | Min. -30 °C |
| Ambient Temperature (Non-Horizontal Installation) | Max. 60 °C |
| Width | 50 mm |
| Height | 117 mm |
| Depth | 74 mm |
