SIEMENS SIMATIC S7-1500F CPU 1515F-2 PN
A high-performance failsafe central processing unit designed for advanced industrial automation and safety-related applications. This CPU combines fast processing, integrated safety functionality, and flexible communication, making it ideal for complex control systems in demanding industrial environments. Manufacturer: Siemens
Type: Central Processing Unit
Model: CPU 1515F-2 PN
MRN: 6ES7 515-2FM02-0AB0
Family: SIMATIC S7-1500F
HW Functional Status: FS01
Firmware Version: V2.9
| Screen Diagonal | 6.1 cm |
| Control Elements “ Number Of Keys | 8 |
| Mode Buttons | 2 |
| Supply Voltage (Rated, DC) | 24 V |
| Permissible Voltage Range (DC) | 19.2 V to 28.8 V |
| CPU Processing Time “ Bit Operations (Typical) | 30 ns |
| CPU Processing Time “ Word Operations (Typical) | 36 ns |
| CPU Processing Time “ Fixed Point Arithmetic (Typical) | 48 ns |
| Mains / Voltage Failure Stored Energy Time | 5 ms |
| Repeat Rate (Minimum) | 1/s |
| Input Current “ Rated Consumption | 0.8 A |
| Input Current “ Maximum Consumption | 1.1 A |
| Inrush Current (Maximum, Rated) | 2.4 A |
| Integrated Memory (Program) | 750 kbyte |
| Integrated Memory (Data) | 3 Mbyte |
| Load Memory | SIMATIC Memory Card, up to 32 Gbyte |
| Ambient Temperature (Storage / Transport) | -40 °C to +70 °C |
| Maximum Modules Per Rack | 32 (CPU + 31 modules) |
| Number Of Lines | 1 |
| Width | 70 mm |
| Height | 147 mm |
| Depth | 129 mm |
