Siemens 6SL3201-0BE21-0AA0 Braking Resistor
Neu
Auf Lager1 EinheitVersandbereit
189,99$
Industrial braking resistor designed for drive systems requiring reliable regenerative energy dissipation during motor deceleration. Features 140 Ohm resistance, up to 4 kW maximum rated power, and natural convection cooling.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Ref Code | A5E03347051 |
| Version | e / A03 |
| SN | 02 31121 2 0001 |
| Ref No | 02 31517 1 0140/ 18.42 |
| Rated power | 0.2 kW |
| Rated power, max. | 4 Kw |
| Resistance | 140 ohm |
| DC link voltage | 330 … 840 V |
| DC-link voltage, max. | 840 V |
| Dimensions | Width 105 mm (4.13 in), Height 345 mm ,Depth 100 mm |
| Input current, max. | 2.5 A |
| Conductor cross-section | 2.5 mm² (AWG 14) |
| Cooling method | natural convection |
| Ambient temperature in operation | -25 … 40 °C (-13 … 104 °F) |
| Protection Class | IP20 |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1099351 |
| Weight | 2,6 |
