SKF 241/500 ECA/W33 Spherical Roller Bearing
Neu
Auf Lager2 EinheitenVersandbereit
21 999,99$
SPHERICAL ROLLER BEARING SKF 241/500 ECA/W33 Kugellager mit 530 mm Bohrung, Messingkäfig und W33-Schmierung, entwickelt für schwere industrielle Lasten mit optimaler Geschwindigkeit und Haltbarkeit.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF 241/500 ECA/W33 SPHERICAL ROLLER BEARING
This heavy-duty spherical roller bearing from SKF is designed for large-scale industrial applications with demanding radial and axial loads. The brass cage ensures strength and durability, while the W33 design facilitates optimal lubrication through an annular groove and three lubrication holes in the outer ring.
Manufacturer: SKF
Type: Spherical Roller Bearing
Model: 241/500 ECA/W33
Failing Frequencies
| Bore Diameter (d) | 530 mm |
| Outer Diameter (D) | 830 mm |
| Width | 325 mm |
| Dynamic Load Rating | 10123 N |
| Static Load Rating | 17000 N |
| Fatigue Load Limit | 1120 N |
| Limiting Speed | 380 RPM |
| Reference Speed | 260 RPM |
| Design | W33 (Annular groove with three lubrication holes in the outer ring) |
| Cage | Brass |
| BPFO (Ball Pass Frequency Outer) | 8.714 |
| BPFI (Ball Pass Frequency Inner) | 11.286 |
| BSF (Ball Spin Frequency) | 3.708 |
| FTF (Fundamental Train Frequency) | 0.436 |
