SKF 3205 A-2RS1TN9/MT33 Angular Contact Ball Bearing
Neu
Auf Lager1 EinheitVersandbereit
SKF Rillenkugellager mit Doppellauf und 25 mm Bohrung, 52 mm Außendurchmesser und 30° Kontaktwinkel, mit Dichtungsdesign, Nylonkäfig und Hochleistungsfett MT33 für Haltbarkeit und Geschwindigkeit.
253205A-2RS1TN9/MT33AngularBallbearingboreCageContactDoubleGreaseHigh-SpeedIndustrialmmMT33NylonRowSealedSKF
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF 3205 A-2RS1TN9/MT33 ANGULAR CONTACT BALL BEARING
This double-row angular contact ball bearing from SKF is engineered for high-performance applications where axial and radial loads must be handled simultaneously. Featuring a robust sealing system, a high-speed nylon cage, and temperature-stable MT33 grease, it's ideal for demanding industrial environments.
Manufacturer: SKF
Type: Angular Contact Ball Bearing
Model: 3205 A-2RS1TN9/MT33
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 52 mm |
| Width (B) | 20.6 mm |
| Contact Angle | 30° |
| Dynamic Load Rating (Cr) | 22000 N |
| Static Load Rating (C0r) | 15300 N |
| Fatigue Load Limit | 640 N |
| Limiting Speed | 8500 rpm |
| Cage | TN9 “ Non-metallic, Nylon glass fibre filled |
| Sealing | 2RS1 “ Sealed on both sides |
| Design | MT33 “ Medium temperature grease (mineral oil-based, lithium thickened) |
