SKF 51113 Thrust Ball Bearing

Manufacturer: SKF

Type: Thrust ball bearings single direction

Model: 51113



Dimensions

Bore diameter d: 65 mm

Outer diameter D: 90 mm

Height T: 18 mm

Outside diameter shaft washer d₁: 90 mm

Inner diameter housing washer D₁: 67 mm

Minimum chamfer dimension r _1,2: 1 mm

Basic load ratings:

Dynamic C: 37700 N

Static C₀: 108000 N

Reference speed: 4800 rpm

Limiting speed: 3400 rpm

Cage: Sheet Metal

Axial load capability: Single-direction
