SKF 7310 Becm Angular Contact Ball Bearing
Neu
Auf Lager1 EinheitVersandbereit
66,66$
Angular Contact Kugellager SKF einreihiges Angular Contact Kugellager mit 40° Kontaktwinkel, Messingkäfig, Genauigkeitsklasse P6 und hoher Tragfähigkeit für industrielle Anwendungen.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF 7310BECM Angular Contact Ball Bearing
The SKF 7310BECM is a single row angular contact ball bearing designed to accommodate combined radial and axial loads while providing high running accuracy and reliable performance in industrial applications.
Manufacturer: SKF
Type: Single Row Angular Contact Ball Bearing
Model: 7310BECM
Load Ratings & Speed
Design & Accuracy
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 110 mm |
| Width (B) | 27 mm |
| Contact Angle | 40 Degrees |
| Basic Dynamic Load Rating (Cr) | 75,000 N |
| Basic Static Load Rating (C0r) | 51,000 N |
| Fatigue Load Limit | 2.16 kN |
| Limiting Speed | 10,000 rpm |
| Reference Speed | 8,000 rpm |
| Cage | Brass |
| Matched Arrangement | No |
| Universal Matching Bearing | Yes |
| Axial Internal Clearance | Not Applicable |
| Tolerance Class | Class 6 (P6) |
