SKF 7314 AMDB/C3 Angular Contact Ball Bearing
Winkelkontakt-Kugellager SKF 7314 AMDB/C3 einreihiges Winkelkontakt-Kugellager mit Rücken-an-Rücken-Anordnung und C3-Spiel für hochpräzise Industrieanwendungen.
SKF 7314 AMDB/C3 Single Row Angular Contact Ball Bearing Set
A high-precision single row angular contact ball bearing set manufactured by SKF, designed to support combined radial and axial loads with high rigidity and reliable performance. This bearing set features a back-to-back arrangement and C3 internal clearance, making it suitable for demanding industrial and mechanical applications requiring stability and accuracy.
Manufacturer: SKF
Type: Single Row Angular Contact Ball Bearing
Model: 7314 AMDB/C3
Application:
High-speed rotating machinery, gearboxes, electric motors, pumps, and industrial equipment requiring precise axial positioning and high load-carrying capability
| Bore Diameter (d) | 70 mm |
| Outer Diameter (D) | 150 mm |
| Width (B) | 35 mm |
| Contact Angle | 30 degrees |
| Cage | Brass |
| Arrangement | DB, Back-to-back arrangement |
| Clearness | C3 |
| No. of Items per Set | 2 |
