SKF NATR6X Yoke Type Track Roller
Gabel-Trackrolle Die SKF NATR 6 X Gabel-Trackrolle verfügt über einen Bohrungsdurchmesser von 6 mm, einen Außendurchmesser von 19 mm und eine dynamische Tragfähigkeit von 3,3 kN, und bietet hohe Leistung und Abdichtung für industrielle Anwendungen, die Präzision und Stabilität erfordern.
SKF NATR 6 X Yoke Type Track Roller
The SKF NATR 6 X Yoke Type Track Roller is designed to provide reliable and high-performance operation for heavy-duty industrial systems. Featuring a profiled outer diameter with an inner ring, this track roller ensures smooth and efficient operation in various industrial settings.
Manufacturer: SKF
Type: YOKE TYPE TRACK ROLLER
Model: NATR 6 X
Basic Load Ratings:
This SKF yoke-type track roller is engineered to deliver high performance under heavy loads, ensuring smooth operation and long-lasting stability in industrial machinery.
| Bore Diameter (d) | 6 mm |
| Outer Diameter (D) | 19 mm |
| Width, Total | 12 mm |
| Width, Outer Ring | 11 mm |
| Dynamic Load Rating (Cr) | 3.3 kN |
| Static Load Rating (C0r) | 3.8 kN |
| Fatigue Load Limit | 0.415 kN |
| Limiting Speed | 5600 r/min |
| Radial Internal Clearance | Between C2 and CN |
| Sealing | Gap-type seal on both sides |
