Tedea Huntleigh 0220 MAX 20000 KG High Accuracy Compression Load Cell
Manufacturer: TEDEA-HUNTLEIGH
Type: High Accuracy Compression Load Cell
Model: 0220
FEATURES
- Capacities 20000 Kg
- Stainless Steel Construction
- OIML R60 And NTEP Approved
- IP68 Protection
- Optional
- EEX IA IIC T6 Hazardous Area Approval
- FM Approval Available
APPLICATIONS
- Truck scales
- Hopper for process weighing
- Tank and silo weighing
- Harsh environment
Maximum weight limit (E max): 20000 kg
Rated Output: 2.0 mV/V
Temperature Compensation: -10…40 °C
Input Impedance: 1065±60 Ω
Output Impedance: 1025±20 Ω
Cable Length: 5 m
Cable Type: 6-Wire, Braided, Polyurethane, Dual Floating Screen
Class: C4
Protection Class: IP68
Weight: 3.325 kg
