Telco SMR 6400 TS J Photoelectric Sensor
Neu
Auf Lager2 EinheitenVersandbereit
Thru Beam Photoelectric Sensor
The Telco SMR6400 TS J is a thru beam photoelectric sensor with a 6-meter sensing range. Featuring an IP67 stainless steel housing, it operates at 10 to 32 V DC and provides reliable object detection in harsh industrial environments.6beamcomasIndustrialIP67JLightMeterNpn/PnpOutputPhotoelectricRangeReceiverSensingSensorSMR6400stainlessSteelTelcoThruTS
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Telco SMR6400 TS J “ Thru Beam Photoelectric Sensor
The Telco SMR6400 TS J thru beam photoelectric sensor offers reliable and precise object detection in industrial applications. Designed for high performance, it features a stainless steel housing and provides excellent protection against dust and water with an IP67 rating.
Manufacturer: Telco
Type: Thru Beam Photoelectric Sensor
Model: SMR6400 TS J
Part No.: 0469138900
COMAS Part No.: 0421.636.100.010
Order Code: 010
| Operation Mode | Thru Beam |
| Function | Light Receiver |
| Supply Voltage | 10 to 32 V DC |
| Sensing Range | 6 m |
| Output | NPN/PNP |
| Output Status | NO (Normally Open) |
| Housing | M12 x 1 |
| Housing Material | Stainless Steel |
| Connection | 4 pin, M12 plug |
| Current Consumption | Max. 320 mW |
| Max. Output Load | 100 mA |
| Max. Residual Voltage | 2.5 V |
| Max. Operation Frequency | 100 Hz |
| Operation Temperature | -20 to +60 °C |
| Sealing Class | IP 67 |
