Telemecanique XML B002A2S11 Pressure Switch

Manufacturer: TELEMECANIQUE
Type: Pressure switch
Model: XMLB002A2S11

Device short name: XMLB
Pressure rating: 2.5 bar
Controlled fluid:
Air (0…70 °C)
Fresh water (0…70 °C)
Hydraulic oil (0…70 °C)
Fluid connection type: G 1/4 (female) conforming to ISO 228
Electrical connection: Screw-clamps terminals, 1 x 0.5…2 x 2.5 mm²
,1 connector Pg 13
Cable entry: Cable gland 9…13 mm
Contacts type and composition: 1 C/O
Pressure switch type of operation: Regulation between 2 thresholds
Electrical circuit type: Control circuit
Scale type: Adjustable differential
Adjustable range of switching point on rising pressure: 0.3…2.5 bar
Adjustable range of switching point on falling pressure: 0.14…2.29 bar
Possible differential maximum at high setting: 1.75 bar
Maximum permissible accidental pressure: 9 bar
Destruction pressure: 18 bar
Pressure actuator: Diaphragm
