THK SR25W1SS Linear Guideway Block
Neu
Auf Lager8 EinheitenVersandbereit
88,88$
Linearführungsblock Der THK SR25W1SS Linearführungsblock bietet eine reibungslose, präzise lineare Bewegung mit einem quadratischen Blockdesign, hoher Tragfähigkeit und fortschrittlicher Dichtung für industrielle Anwendungen.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
THK SR25W1SS Linear Guideway Block
The THK SR25W1SS Linear Guideway Block is engineered for high-precision applications requiring smooth and reliable linear motion. Designed with a robust square block type, this guideway block offers enhanced load-bearing capacity and superior sealing performance for industrial automation and machinery.
Manufacturer: THK
Type: Linear Guideway Block
Model: SR25W1SS
Basic Load Ratings:
| Size | 25 |
| Length | 83 mm |
| Width | 48 mm |
| Height | 33 mm |
| Height of Block | 26 mm |
| Block Type | Square |
| Dynamic Load Rating | 30.9 kN |
| Static Load Rating | 44.7 kN |
| Mounting Hole | M6×9 |
| Tapped Holes | 4 |
| Seal | 1SS, with End Seal, Side Seal, and Inner Seal |
| Classification of the LM Block | W |
