Hydraulics & Pneumatics Pneumatic Actuators

Univer W1010800010M Short Stroke Cylinder

Name: UNIVER W1010800010M SHORT STROKE CYLINDER
SKU: 971587
Price: 133.33 USD
Availability: InStock

univer-w1010800010m-short-stroke-cylinder-1

univer-w1010800010m-short-stroke-cylinder-2

Neu

Auf Lager2 EinheitenVersandbereit

133,33$

SHORT-STROKE CYLINDER

UNIVER W101-080-0010-M double acting short-stroke cylinder with 80 mm bore, 10 mm stroke, G 3/8 ports, anodized aluminium barrel, and stainless steel piston rod.

Hersteller

UNIVER ?

SKU

971587

Kategorie

Pneumatic Actuators

Zustand

Neu

10 3/8 80 Acting Aluminium Automation bore Cylinder Double G mm Piston Pneumatic Port ROD Short-Stroke stainless Steel Stroke Univer W101-080-0010-M

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

UNIVER W101-080-0010-M Double Acting Short-Stroke Cylinder

The UNIVER W101-080-0010-M is a robust double acting short-stroke cylinder designed for reliable performance in pneumatic applications. Constructed with anodized aluminium barrel, aluminium piston and end-caps, and stainless steel piston rod, it offers durability, precision, and long service life under demanding conditions.

Manufacturer: UNIVER

Type: Double Acting Short-Stroke Cylinder

Model: W101-080-0010-M

Material	Barrel: Anodized Aluminium; Piston and End-Caps: Aluminium; Piston Rod: Stainless Steel
Stroke Length	10 mm
Bore Size	80 mm
Piston Rod End	Female thread
Port Size	G 3/8
Variants	Standard
Operating Pressure	1.5 / 10 bar
Mode of Operation	Double-acting
Fluid	Filtered air
Magnet	With Magnet
Temperature Range	-20 / 80 °C
