Vemer VM7341 Current Transformer
Neu
Auf Lager4 EinheitenVersandbereit
Current Transformer
The Vemer VM7341 / TU-60 current transformer features a 800/5 A current ratio and a knee-point voltage class range. With a 48 kA thermal current rating, this transformer is designed for reliable performance in high-voltage electrical applications.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Vemer VM7341 / TU-60 “ Current Transformer
The Vemer VM7341 / TU-60 current transformer is designed to provide reliable and precise measurements in high-voltage electrical systems. With a broad range of knee-point voltage classes and thermal current capacity, this transformer is suitable for industrial applications requiring robust performance.
Manufacturer: Vemer
Type: Current Transformer
Model: VM7341 / TU-60
| Primary/Secondary Current | 800/5 A |
| Primary/Secondary Voltage | 0.6/3 Kv |
| Knee-Point Voltage Class | 0.5 (15 VA) - 1 (20 VA) - 3 (30 VA) |
| Frequency | 50 to 60 Hz |
| Thermal Current Ith | 48 kA |
| Dimensions | 105 x 137 x 87 mm |
| Diameter | 51 mm |
