ZKL NU 224.MAC3 Cylindrical Roller Bearing
Gebraucht
Auf Lager3 EinheitenVersandbereit
Zylindrisches Wälzlager ZKL NU 224.MAC3 zylindrisches Wälzlager mit C3-Spiel, Messingkäfig und hoher radialer Tragfähigkeit für den industriellen Maschinenbau.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
ZKL NU 224.MAC3 Cylindrical Roller Bearing
The ZKL NU 224.MAC3 cylindrical roller bearing is designed to accommodate high radial loads while maintaining reliable performance in demanding industrial applications. Its C3 internal clearance and brass cage ensure stable operation at elevated speeds and under heavy load conditions.
Manufacturer: ZKL
Type: Cylindrical Roller Bearing
Model: NU 224.MAC3
| Bore Diameter (d) | 120 mm |
| Outer Diameter (D) | 215 mm |
| Width (B) | 40 mm |
| Dynamic Load Rating (Cr) | 261 kN |
| Static Load Rating (C0r) | 299 kN |
| Fatigue Load Rating | 31.24 kN |
| Limiting Speed (Grease Lubrication) | 3000 rpm |
| Limiting Speed (Oil Lubrication) | 3500 rpm |
| Internal Clearance | C3 |
| Cage Material | Brass |
