Advantech ADAM-4520 Isolated Converter
新着
在庫あり1 ユニット即納可能
Industrial isolated RS-232 to RS-422/485 converter featuring 3,000 VDC isolation, 115.2 kb/s data rate, 2 communication ports, and a wide 10-30 VDC power supply range for reliable industrial networking applications.
大量在庫
グローバル配送
専門的なサポート
品質保証
| Part No. | ADAM-4520-D2E |
| Rev | A0/ D2E |
| MO No | C54520D4 |
| SN | IAA7377078 |
| Range | ADAM |
| Number of Channels/Ports | 2 Port |
| Maximum Data Rate | 115.2 kb/s |
| Interface Type | RS-232/422/485 |
| Supply Voltage | 10-30 V |
| Minimum Operating Temperature | - 10 C |
| Maximum Operating Temperature | + 70 C |
| Description/Function | Isolated RS-232 to RS-422/485 Converter |
| Connectors | 1 x plug-in terminal block |
| Isolation Voltage | 3,000 VDC |
| Power Consumption Typical | 0.8 WAT 24 VDC Max.: 1 W AT 24 V |
| Speed Modes (bps) | 1,200, 2,400, 4,800, 9,600, 19.2 k, 38.4 k, 57.6 k, 115.2 k, RTS control and RS-422 (switchable) |
| Standard | RoHS |
| Stock Key | EU002 |
| Condition | New |
| SKU | 1099448 |
| Weight | 0,22 |
