Allen Bradley 1762-L40BWA Programmable Logic Controller
新着
ご依頼に応じて対応可能
PROGRAMMABLE LOGIC CONTROLLER (PLC)
Allen Bradley 1762L40BWA PLC from the MicroLogix 1200 Series C offers powerful I/O, serial connectivity, and expansion up to 136 points.12001762L40BWAAllenAutomationBradleyControlControllerDigitalexpansionIndustrialInputLogicMicroLogixModularOutputPLCprogrammableRelayRS232RS485System
大量在庫
グローバル配送
専門的なサポート
品質保証
ALLEN BRADLEY 1762L40BWA PROGRAMMABLE LOGIC CONTROLLER (PLC)
This high-performance MicroLogix 1200 Series C PLC is engineered for industrial-grade control systems, offering a powerful I/O setup, reliable communication interfaces, and modular expandability.
Manufacturer: Allen Bradley
Type: Programmable Logic Controller (PLC)
Model: 1762L40BWA
MNR: 2L40BWA**CH1221111566
Series: C / MicroLogix TM 1200
Revision: H
I/O and Power Configuration
- I/O: 24 × 24¯V¯DC inputs (20 standard + 4 fast), 16 × relay outputs
- Power Supply: 100 to 240¯V¯AC, 50 to 60 Hz, 82 VA max
- Relay Output Capacity: 1440 VA max
- Control Power: Internal, 68 to 82 VA usage depending on version
Interfaces and Memory
- Serial Interface: RS-232C (isolated) / RS-485
- Memory: 6¯KB user memory (approx. 4¯K program, 2¯K data)
Environmental and Physical Specs
- Operating Temperature: 0 to 55¯°C
- Dimensions: 90¯mm H (104¯mm open), 160¯mm W, 87¯mm D
Expansion Capabilities
- Built-in high-speed 20¯kHz counter
- Programmable limit switch
- Expandable to 136 I/O via up to six expansion modules
