Allen Bradley 1762-L40BWA Programmable Logic Controller

ALLEN BRADLEY 1762L40BWA PROGRAMMABLE LOGIC CONTROLLER (PLC)

This high-performance MicroLogix 1200 Series C PLC is engineered for industrial-grade control systems, offering a powerful I/O setup, reliable communication interfaces, and modular expandability.

Manufacturer: Allen Bradley
Type: Programmable Logic Controller (PLC)
Model: 1762L40BWA
MNR: 2L40BWA**CH1221111566
Series: C / MicroLogix TM 1200
Revision: H

I/O and Power Configuration

• I/O: 24 × 24¯V¯DC inputs (20 standard + 4 fast), 16 × relay outputs
• Power Supply: 100 to 240¯V¯AC, 50 to 60 Hz, 82 VA max
• Relay Output Capacity: 1440 VA max
• Control Power: Internal, 68 to 82 VA usage depending on version

Interfaces and Memory

• Serial Interface: RS-232C (isolated) / RS-485
• Memory: 6¯KB user memory (approx. 4¯K program, 2¯K data)

Environmental and Physical Specs

• Operating Temperature: 0 to 55¯°C
• Dimensions: 90¯mm H (104¯mm open), 160¯mm W, 87¯mm D

Expansion Capabilities

• Built-in high-speed 20¯kHz counter
• Programmable limit switch
• Expandable to 136 I/O via up to six expansion modules
