Hohner 70-140 CA-1024 Absolute Encoder
在庫あり1 ユニット即納可能
160,00$
ABSOLUTE ENCODER Hohner 70-140-CA-1024は、ステンレス鋼の一体軸、IP54保護、1024ステップを備えた高解像度絶対エンコーダーで、産業環境およびオートメーションシステムに適しています。
102470-140-CA-1024AbsoluteAutomationEncoderHighHohnerHousingIndustrialIP54OutputPNPResolutionshaftstainlessSteelStepZinc
大量在庫
グローバル配送
専門的なサポート
品質保証
HOHNER 70-140-CA-1024 ABSOLUTE ENCODER
Engineered for precise motion control in industrial automation systems, the Hohner 70-140-CA-1024 Absolute Encoder provides dependable performance with a compact, robust design. Featuring a stainless steel solid shaft and high-resolution output, this encoder is ideal for high-speed and harsh environment applications.
Manufacturer: HOHNER
Type: Absolute Encoder
Model: 70-140-CA-1024
REF No.: 5325-99
| Shaft Diameter | 6 mm |
| Shaft Design | Stainless Steel Solid |
| Resolution | 1024 |
| Voltage Supply | 10 / 30 VDC |
| Output Current | 40 mA |
| Output Circuit | PNP |
| Counting Direction | Counting Direction Switchover |
| Output Code | Grey |
| Max Speed | 6,000 U/min |
| Max Pulse Frequency | 25 kHz |
| Protection Class | IP 54 |
| Housing Material | Zinc Die-Casting |
| Operating Temperature | -30 / 70 °C |
